72V36100L6PFG の詳細情報

  • 仕様・詳細
  • メーカー情報
型番72V36100L6PFG
メーカーIDT
Access Time-Max 4 ns
Additional Feature RETRANSMIT; AUTO POWER DOWN; ASYNCHRONOUS MODE IS ALSO POSSIBLE
Clock Frequency-Max (fCLK) 166 MHz
Cycle Time 6 ns
JESD-30 Code R-PQFP-G128
JESD-609 Code e3
Length 20 mm
Memory Density 2359296 bit
Memory IC Type OTHER FIFO
Memory Width 36
Moisture Sensitivity Level 3
Number of Functions 1
Number of Terminals 128
Number of Words 65536 words
Number of Words Code 64K
Operating Mode SYNCHRONOUS
Operating Temperature-Max 70 Cel
Operating Temperature-Min 0 Cel
Organization 64KX36
Output Enable YES
Package Body Material PLASTIC/EPOXY
Package Code LFQFP
Package Equivalence Code QFP128,.63X.87,20
Package Shape RECTANGULAR
Package Style FLATPACK, LOW PROFILE, FINE PITCH Meter
Parallel/Serial PARALLEL
Peak Reflow Temperature (Cel) 260
Power Supplies 3.3 V
Qualification Status Not Qualified
Seated Height-Max 1.6 mm
Standby Current-Max 0.015 Amp
Sub Category FIFOs
Supply Current-Max 0.04 mA
Supply Voltage-Max (Vsup) 3.45 V
Supply Voltage-Min (Vsup) 3.15 V
Supply Voltage-Nom (Vsup) 3.3 V
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Pitch 0.5 mm
Terminal Position QUAD
Time@Peak Reflow Temperature-Max (s) 30
Width 14 mm
