49FCT805SO Idt

49FCT805SO
49FCT805SO
49FCT805SO

49FCT805SO - IDT の商品詳細ページです。

1

20時間3分後 以内に見積もり依頼を頂ければ、
05月15日(水) 9:00 までに見積もり回答いたします。

  • 個
この商品のお問い合わせ

49FCT805SO の詳細情報

  • 仕様・詳細
  • メーカー情報
型番49FCT805SO
メーカーIDT
Family FCT
Input Conditioning SCHMITT TRIGGER
JESD-30 Code R-PDSO-G20
JESD-609 Code e0
Length 12.8 mm
Logic IC Type LOW SKEW CLOCK DRIVER
Max I(ol) 0.064 Amp
Moisture Sensitivity Level 1
Number of Functions 2
Number of Inverted Outputs 0
Number of Terminals 20
Number of True Outputs 5
Operating Temperature-Max 70 Cel
Operating Temperature-Min -40 Cel
Output Characteristics 3-STATE
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Equivalence Code SOP20,.4
Package Shape RECTANGULAR
Package Style SMALL OUTLINE Meter
Peak Reflow Temperature (Cel) 225
Power Supplies 5 V
Power Supply Current-Max (ICC) 8.5 mA
Prop. Delay@Nom-Sup 5.6 ns
Propagation Delay (tpd) 5.6 ns
Qualification Status Not Qualified
Same Edge Skew-Max (tskwd) 0.7 ns
Seated Height-Max 2.35 mm
Sub Category Clock Drivers
Supply Voltage-Max (Vsup) 5.25 V
Supply Voltage-Min (Vsup) 4.75 V
Supply Voltage-Nom (Vsup) 5 V
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Pitch 1.27 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 20
Width 7.5 mm
会社名称Integrated Device Technology, Inc.
設立1980
所在地6024 Silver Creek Valley Road, San Jose, CA 95138 USA
URLhttp://www.idt.com/
