H5TQ4G63AFR-PBC

Name: H5TQ4G63AFR-PBC
Brand: HYNIX
SKU: 180150346-0000-0000-0000

H5TQ4G63AFR-PBC - HYNIX の商品詳細ページです。

２営業日以内に回答いたします

H5TQ4G63AFR-PBC の詳細情報

型番	H5TQ4G63AFR-PBC
メーカー	HYNIX
Access Mode	MULTI BANK PAGE BURST
Access Time-Max	0.225 ns
Additional Feature	AUTO/SELF REFRESH
Clock Frequency-Max (fCLK)	800 MHz
I/O Type	COMMON
Interleaved Burst Length	4,8
JESD-30 Code	R-PBGA-B96
Length	13 mm
Memory Density	4294967296 bit
Memory IC Type	DDR3 DRAM
Memory Width	16
Number of Functions	1
Number of Ports	1
Number of Terminals	96
Number of Words	268435456 words
Number of Words Code	256M
Operating Mode	SYNCHRONOUS
Operating Temperature-Max	85 Cel
Operating Temperature-Min	0 Cel
Organization	256MX16
Output Characteristics	3-STATE
Package Body Material	PLASTIC/EPOXY
Package Code	TFBGA
Package Equivalence Code	BGA96,9X16,32
Package Shape	RECTANGULAR
Package Style	GRID ARRAY, THIN PROFILE, FINE PITCH Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	1.5 V
Qualification Status	Not Qualified
Refresh Cycles	8192
Seated Height-Max	1.2 mm
Self Refresh	YES
Sequential Burst Length	4,8
Standby Current-Max	0.017 Amp
Sub Category	DRAMs
Supply Current-Max	0.22 mA
Supply Voltage-Max (Vsup)	1.575 V
Supply Voltage-Min (Vsup)	1.425 V
Supply Voltage-Nom (Vsup)	1.5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	OTHER
Terminal Form	BALL
Terminal Pitch	0.8 mm
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	9 mm
