HD74LS123

Name: HD74LS123
Brand: HITACHI
SKU: 400064398-0000-0000-0000

HD74LS123 - HITACHI の商品詳細ページです。

２営業日以内に回答いたします

HD74LS123 の詳細情報

型番	HD74LS123
メーカー	HITACHI
種別	アドバンストLS-TTL
Family	LS
JESD-30 Code	R-PDIP-T16
JESD-609 Code	e0
Length	9.9 mm
Logic IC Type	MONOSTABLE MULTIVIBRATOR
Moisture Sensitivity Level	1
Number of Data/Clock Inputs	2
Number of Functions	2
Number of Terminals	16
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-20 Cel
Output Polarity	COMPLEMENTARY
Package Body Material	CERAMIC
Package Code	DIP
Package Equivalence Code	DIP16,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	5 V
Propagation Delay (tpd)	56 ns
Qualification Status	Not Qualified
Seated Height-Max	1.75 mm
Sub Category	Prescaler/Multivibrators
Supply Voltage-Max (Vsup)	5.25 V
Supply Voltage-Min (Vsup)	4.75 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	NO
Technology	TTL
Temperature Grade	COMMERCIAL
Terminal Finish	NICKEL PALLADIUM GOLD
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	20
Width	3.9 mm
