HD61602R

Name: HD61602R
Brand: HITACHI
SKU: 180070841-0000-0000-0000

HD61602R - HITACHI の商品詳細ページです。

２営業日以内に回答いたします

HD61602R の詳細情報

型番	HD61602R
メーカー	HITACHI
Data Input Mode	SERIAL/PARALLEL
Display Mode	SEGMENT
Interface IC Type	LIQUID CRYSTAL DISPLAY DRIVER
JESD-30 Code	R-PQFP-G80
JESD-609 Code	e0
Length	14 mm
Multiplexed Display Capability	NO
Number of Backplanes	4-BP
Number of Functions	1
Number of Segments	64
Number of Terminals	80
Operating Temperature-Max	75 Cel
Operating Temperature-Min	-20 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	QFP
Package Equivalence Code	QFP80,.7SQ
Package Shape	RECTANGULAR
Package Style	FLATPACK Meter
Power Supplies	2.2/5.5 V
Qualification Status	Not Qualified
Seated Height-Max	3.05 mm
Sub Category	Other Interface ICs
Supply Current-Max	0.1 mA
Supply Voltage-Max	5.5 V
Supply Voltage-Min	2.2 V
Supply Voltage-Nom	3.8 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL EXTENDED
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	QUAD
Width	14 mm
fmax-Min	0.13 MHz
