HD14051BFP

Name: HD14051BFP
Brand: HITACHI
SKU: 180048994-0000-0000-0000

HD14051BFP - HITACHI の商品詳細ページです。

２営業日以内に回答いたします

CMOS標準ロジックIC|8chアナログ・マルチプレクサ/デマルチプレクサ（アナログスイッチ） | 16ピン|パッケージ：SOP(JEITA)

HD14051BFP の詳細情報

型番	HD14051BFP
メーカー	HITACHI
種別	CMOS標準ロジックIC
Analog IC - Other Type	SINGLE-ENDED MULTIPLEXER
JESD-30 Code	R-PDSO-G16
Length	10.06 mm
Number of Channels	8
Number of Functions	1
Number of Terminals	16
On-state Resistance Match-Nom	25 ohm
On-state Resistance-Max (Ron)	1050 ohm
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Qualification Status	Not Qualified
Seated Height-Max	2.2 mm
Supply Voltage-Max (Vsup)	18 V
Supply Voltage-Min (Vsup)	3 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Switch-off Time-Max	2125 ns
Switch-on Time-Max	2125 ns
Temperature Grade	INDUSTRIAL
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Width	5.5 mm
