2SC2736

Name: 2SC2736
Brand: HITACHI
SKU: 30082271-0000-0000-0000

2SC2736 - HITACHI の商品詳細ページです。

２営業日以内に回答いたします

NPN型バイポーラトランジスタ | 高周波用

2SC2736 の詳細情報

型番	2SC2736
メーカー	HITACHI
種別	バイポーラトランジスタ
Additional Feature	LOW NOISE
Collector Current-Max (IC)	0.05 A
Collector-base Capacitance-Max	1 pF
Collector-emitter Voltage-Max	20 V
Configuration	SINGLE
DC Current Gain-Min (hFE)	30
Highest Frequency Band	ULTRA HIGH FREQUENCY BAND
JESD-30 Code	R-PDSO-G3
Number of Elements	1
Number of Terminals	3
Operating Temperature-Max	150 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Polarity/Channel Type	NPN
Power Dissipation-Max (Abs)	0.15 W
Qualification Status	Not Qualified
Sub Category	Other Transistors
Surface Mount	YES
Terminal Form	GULL WING
Terminal Position	DUAL
Transistor Application	AMPLIFIER
Transistor Element Material	SILICON
Transition Frequency-Nom (fT)	1400 MHz
VCEsat-Max	0.7 V
