1S2076 データシート

Name: 1S2076
Brand: HITACHI
SKU: 20496475-0000-0000-0000

1S2076 - HITACHI の商品詳細ページです。

No Image

２営業日以内に回答いたします

1S2076 の詳細情報

型番	1S2076
メーカー	HITACHI
データシート
Additional Feature	HIGH RELIABILITY
Application	GENERAL PURPOSE
Case Connection	ISOLATED
Configuration	SINGLE
Diode Capacitance-Max	3 pF
Diode Element Material	SILICON
Diode Type	MIXER DIODE
Forward Voltage-Max (VF)	0.8 V
JEDEC-95 Code	DO-35
JESD-30 Code	O-GALF-W2
JESD-609 Code	e0
Moisture Sensitivity Level	1
Non-rep Pk Forward Current-Max	1 A
Number of Elements	1
Number of Phases	1
Number of Terminals	2
Operating Temperature-Max	175 Cel
Output Current-Max	0.15 A
Package Body Material	CERAMIC, GLASS-SEALED
Package Shape	ROUND
Package Style	LONG FORM Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Dissipation-Max	0.25 W
Qualification Status	Not Qualified
Rep Pk Reverse Voltage-Max	35 V
Reverse Current-Max	0.1 uA
Reverse Recovery Time-Max	0.003 us
Reverse Test Voltage	30 V
Sub Category	Rectifier Diodes
Surface Mount	NO
Technology	PLANAR DOPED BARRIER
Terminal Finish	TIN COPPER
Terminal Form	WIRE
Terminal Position	AXIAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
