UX60SC-MB-5ST データシート

Name: UX60SC-MB-5ST
Brand: HIROSE
SKU: 310095050-0000-0000-0000

UX60SC-MB-5ST - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

UX60SC-MB-5ST の詳細情報

型番	UX60SC-MB-5ST
メーカー	HIROSE
データシート
Body/Shell Style	RECEPTACLE
Connector Type	TELECOM AND DATACOM CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Finish - Termination	Gold (Au)
Contact Gender	FEMALE
Contact Material	NOT SPECIFIED
Contact Resistance	50 mohm
DIN Conformance	NO
Empty Shell	NO
Filter Feature	YES
IEC Conformance	NO
Insulation Resistance	100000000 ohm
Insulator Material	SYNTHETIC RESIN
JESD-609 Code	e3
MIL Conformance	NO
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	1
Number of Ports	1
Operating Temperature-Max	75 Cel
Operating Temperature-Min	-30 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	RECTANGULAR
Rated Current (Signal)	1 A
Reference Standard	UL
Reliability	COMMERCIAL
Shell Finish	TIN
Shell Material	COPPER ALLOY
Sub Category	Telecom and Datacom Connectors
Terminal Pitch	.7874 mm
Termination Type	SURFACE MOUNT
Total Number of Contacts	5
UL Flammability Code	94V-0
