TM30P-66P データシート

Name: TM30P-66P
Brand: HIROSE
SKU: 400045728-0000-0000-0000

TM30P-66P - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

TM30P-66P の詳細情報

型番	TM30P-66P
メーカー	HIROSE
データシート
Additional Feature	EMI SHIELDED
Body/Shell Style	PLUG
Cable Types	ROUND
Connector Type	TELECOM AND DATACOM CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Finish - Termination	Tin (Sn)
Contact Gender	MALE
Contact Material	NOT SPECIFIED
Contact Resistance	40 mohm
Contact Style	TELCOM, MODULAR
DIN Conformance	NO
Dielectric Withstanding Voltage	300VAC V
Durability	3000 Cycles
Empty Shell	NO
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	250000000 ohm
Insulator Color	BLACK
Insulator Material	POLYCARBONATE
JESD-609 Code	e3
MIL Conformance	NO
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Style	STRAIGHT
Mounting Type	CABLE
Number of Ports	1
Number of Rows Loaded	1
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-30 Cel
Option	GENERAL PURPOSE
Rated Current (Signal)	0.5 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Telecom and Datacom Connectors
Termination Type	WIRE
Total Number of Contacts	6
UL Flammability Code	94V-0
Wire Size-Max	28 AWG
Wire Size-Min	28 AWG
