TM2REA-0604 データシート

Name: TM2REA-0604
Brand: HIROSE
SKU: 300233204-0000-0000-0000

TM2REA-0604 - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

TM2REA-0604 の詳細情報

型番	TM2REA-0604
メーカー	HIROSE
データシート
Additional Feature	GANG-JACKS
Board Mounting Option	SPLIT BOARD LOCK
Body Breadth	0.606 inch
Body Depth	0.63 inch
Body Length	0.677 inch
Body/Shell Style	JACK
Connector Type	TELECOM AND DATACOM CONNECTOR
Contact Finish - Mating	AU
Contact Gender	FEMALE
Contact Material	PHOSPHOR BRONZE
Contact Style	TELCOM, MODULAR
DIN Conformance	NO
Dielectric Withstanding Voltage	500VAC V
Durability	200 Cycles
Empty Shell	NO
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	100000000 ohm
Insulator Color	GRAY
Insulator Material	POLYBUTYLENE TEREPHTHALATE
MIL Conformance	NO
Manufacturer Series	TM2REA
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number of Ports	1
Operating Temperature-Max	60 Cel
Operating Temperature-Min	-25 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	STAGGERED
Rated Current (Signal)	0.5 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Telecom and Datacom Connectors
Terminal Pitch	2.0066 mm
Termination Type	SOLDER
Total Number of Contacts	4
