TM11R-5C-66 データシート

Name: TM11R-5C-66
Brand: HIROSE
SKU: 300388195-0000-0000-0000

TM11R-5C-66 - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

TM11R-5C-66 の詳細情報

型番	TM11R-5C-66
メーカー	HIROSE
データシート
Additional Feature	EMI PROTECTED
Board Mounting Option	PEG
Body Breadth	0.563 inch
Body Depth	0.6 inch
Body Length	0.522 inch
Body/Shell Style	JACK
Connector Type	TELECOM AND DATACOM CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Finish - Termination	NOT APPLICABLE
Contact Gender	FEMALE
Contact Material	NOT SPECIFIED
Contact Style	TELCOM, MODULAR
DIN Conformance	NO
Dielectric Withstanding Voltage	500VAC V
Empty Shell	NO
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	100000000 ohm
Insulator Material	POLYBUTYLENE TEREPHTHALATE
MIL Conformance	NO
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number of Ports	1
Option	GENERAL PURPOSE
PCB Contact Pattern	STAGGERED
Rated Current (Signal)	0.5 A
Reference Standard	UL
Reliability	COMMERCIAL
Shell Finish	TIN
Shell Material	METAL
Sub Category	Telecom and Datacom Connectors
Terminal Length	0.118 inch
Terminal Pitch	2.032 mm
Termination Type	SOLDER
Total Number of Contacts	6
