RM12BRD-7S(71) データシート

Name: RM12BRD-7S(71)
Brand: HIROSE
SKU: 280401479-0000-0000-0000

RM12BRD-7S(71) - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

RM12BRD-7S(71) の詳細情報

型番	RM12BRD-7S(71)
メーカー	HIROSE
データシート
Backshell Type	SOLID
Body Depth	0.335 inch
Body/Shell Style	RECEPTACLE
Connector Type	CIRCULAR CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Finish - Termination	Silver (Ag)
Contact Gender	FEMALE
Contact Material	NOT SPECIFIED
Contact Resistance	4 mohm
Coupling Type	BAYONET
DIN Conformance	NO
Durability	2000 Cycles
Empty Shell	NO
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	1000000000 ohm
Insulator Material	SYNTHETIC RESIN
JESD-609 Code	e4
MIL Conformance	NO
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Option 2	BAYONET
Mounting Style	STRAIGHT
Mounting Type	CABLE AND PANEL
Number of Ports	1
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-25 Cel
Option	GENERAL PURPOSE
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	5 A
Reliability	COMMERCIAL
Shell Finish	NICKEL PLATED
Shell Material	ZINC ALLOY AND BRASS
Shell Size	12
Sub Category	DIN Connectors
Termination Type	SOLDER
Total Number of Contacts	7
