PCN10F-42P-2.54DS(72) データシート

Name: PCN10F-42P-2.54DS(72)
Brand: HIROSE
SKU: 260240274-0000-0000-0000

PCN10F-42P-2.54DS(72) - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

PCN10F-42P-2.54DS(72) の詳細情報

型番	PCN10F-42P-2.54DS(72)
メーカー	HIROSE
種別	コネクタ
データシート
Additional Feature	STANDARD: DIN 41612
Body/Shell Style	PLUG
Connector Type	BOARD EURO CONNECTOR
Contact Finish - Mating	GOLD
Contact Finish - Termination	GOLD
Contact Gender	MALE
Contact Material	BRASS
DIN Conformance	YES
Filter Feature	NO
IEC Conformance	NO
JESD-609 Code	e4
MIL Conformance	NO
Manufacturer Series	PCN10F
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	YES
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number of Rows Loaded	3
Option	GENERAL PURPOSE
Terminal Pitch	2.54 mm
Termination Type	SOLDER
Total Number of Contacts	42
UL Flammability Code	94V-0
