PCN10-32P-2.54DS(72) データシート

Name: PCN10-32P-2.54DS(72)
Brand: HIROSE
SKU: 260227954-0000-0000-0000

PCN10-32P-2.54DS(72) - HIROSE の商品詳細ページです。

No Image

２営業日以内に回答いたします

PCN10-32P-2.54DS(72) の詳細情報

型番	PCN10-32P-2.54DS(72)
メーカー	HIROSE
種別	コネクタ
データシート
Body Breadth	0.339 inch
Body Length	2.101 inch
Body/Shell Style	PLUG
Connector Type	BOARD EURO CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Finish - Termination	Tin (Sn) - with Nickel (Ni) barrier
Contact Gender	MALE
Contact Material	NOT SPECIFIED
Contact Resistance	20 mohm
Contact Style	SQ PIN-SKT
DIN Conformance	YES
Dielectric Withstanding Voltage	1000VAC V
Durability	500 Cycles
Insulator Color	GRAY
Insulator Material	POLYBUTYLENE TEREPHTHALATE
JESD-609 Code	e3
Mating Contact Pitch	0.1 inch
Mounting Option 1	LOCKING
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Name of Rows Loaded	A,B
Number Of PCB Rows	2
Number of Rows Loaded	2
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
PCB Contact Pattern	RECTANGULAR
PCB Contact Row Spacing	2.54 mm
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	2 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Terminal Pitch	2.54 mm
Termination Type	SOLDER
Total Number of Contacts	32
