MQ172X-4PA(11) データシート

Name: MQ172X-4PA(11)
Brand: HIROSE
SKU: 230428489-0000-0000-0000

MQ172X-4PA(11) - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

MQ172X-4PA(11) の詳細情報

型番	MQ172X-4PA(11)
メーカー	HIROSE
データシート
Additional Feature	SHIELDED, LOW PROFILE
Body Breadth	0.154 inch
Body Depth	0.295 inch
Body Length	0.283 inch
Body/Shell Style	RECEPTACLE
Connector Type	TELECOM AND DATACOM CONNECTOR
Contact Arrangement	S0P4
Contact Finish - Mating	AU
Contact Gender	FEMALE
Contact Resistance	30 mohm
DIN Conformance	NO
Durability	5000 Cycles
Empty Shell	NO
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	1000000000 ohm
Insulator Color	BLACK
Insulator Material	SYNTHETIC RESIN
MIL Conformance	NO
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Style	STRAIGHT
Mounting Type	BOARD
Number Of Connectors	ONE
Number of Ports	1
Operating Temperature-Max	75 Cel
Operating Temperature-Min	-30 Cel
Option	GENERAL PURPOSE
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Termination Type	SURFACE MOUNT
Total Number of Contacts	4
