MI20-50PD-SF

Name: MI20-50PD-SF
Brand: HIROSE
SKU: 400069020-0000-0000-0000

MI20-50PD-SF - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

MI20-50PD-SF の詳細情報

型番	MI20-50PD-SF
メーカー	HIROSE
Additional Feature	COMPATIBLE WITH PCMCIA/JEIDA
Board Mounting Option	PEG
Body Breadth	0.15 inch
Body Depth	1.181 inch
Body Length	1.929 inch
Body/Shell Style	RECEPTACLE
Connector Type	PCMCIA CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Finish - Termination	TIN
Contact Gender	MALE
Contact Material	COPPER ALLOY
Contact Pattern	RECTANGULAR
Contact Resistance	40 mohm
Contact Style	SQ PIN-SKT
DIN Conformance	NO
Dielectric Withstanding Voltage	500VAC V
Durability	10000 Cycles
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	1000000000 ohm
Insulator Color	BLACK
Insulator Material	POLYPHENYLENE SULFIDE
JESD-609 Code	e3
MIL Conformance	NO
Mating Contact Pitch	0.05 inch
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	1
Number of Ports	1
Number of Rows Loaded	2
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	RECTANGULAR
Plating Thickness	4u inch
Rated Current (Signal)	0.5 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Terminal Pitch	.635 mm
Termination Type	SURFACE MOUNT
Total Number of Contacts	50
UL Flammability Code	94V-0
