JRC16BP-7P データシート

Name: JRC16BP-7P
Brand: HIROSE
SKU: 200018923-0000-0000-0000

JRC16BP-7P - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

JRC16BP-7P の詳細情報

型番	JRC16BP-7P
メーカー	HIROSE
データシート
Additional Feature	SOLDER TYPE, W/ BAYONET LOCK
Body Breadth	1.063 inch
Body Length	1.063 inch
Body/Shell Style	RECEPTACLE
Connector Type	CIRCULAR CONNECTOR
Contact Finish - Mating	AG
Contact Gender	MALE
Contact Material	COPPER ALLOY
Contact Resistance	5 mohm
Contact Style	RND PIN-SKT
DIN Conformance	YES
Dielectric Withstanding Voltage	1000VAC V
Insulation Resistance	1000000000 ohm
Manufacturer Series	JR
Mounting Option 1	LOCKING MECH
Mounting Style	STRAIGHT
Mounting Type	PANEL
Number of Ports	1
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	10 A
Reference Standard	UL
Reliability	COMMERCIAL
Shell Material	ALUMINUM ALLOY
Sub Category	DIN Connectors
Termination Type	SOLDER LUG
Total Number of Contacts	7
