HS12P-2 データシート

Name: HS12P-2
Brand: HIROSE
SKU: 180048548-0000-0000-0000

HS12P-2 - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

HS12P-2 の詳細情報

型番	HS12P-2
メーカー	HIROSE
データシート
Backshell Type	SOLID
Body Breadth	0.709 inch
Body Length	0.709 inch
Body/Shell Style	PLUG
Connector Type	CIRCULAR CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Gender	FEMALE
Contact Material	NOT SPECIFIED
Contact Resistance	5 mohm
Contact Style	RND PIN-SKT
Coupling Type	SNAP
DIN Conformance	NO
Dielectric Withstanding Voltage	1000VAC V
Empty Shell	NO
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	1000000000 ohm
Insulator Material	SYNTHETIC RESIN
MIL Conformance	NO
Manufacturer Series	HS
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Style	STRAIGHT
Mounting Type	CABLE
Number of Ports	1
Option	GENERAL PURPOSE
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	7 A
Reference Standard	UL
Reliability	COMMERCIAL
Shell Finish	NICKEL PLATED
Shell Material	BRASS
Shell Size	12
Sub Category	DIN Connectors
Terminal Length	0 inch
Termination Type	SOLDER
Total Number of Contacts	2
