H/MS3106A18-10S-D-T データシート

Name: H/MS3106A18-10S-D-T
Brand: HIROSE
SKU: 180108200-0000-0000-0000

H/MS3106A18-10S-D-T - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

H/MS3106A18-10S-D-T の詳細情報

型番	H/MS3106A18-10S-D-T
メーカー	HIROSE
データシート
Additional Feature	STANDARD: MIL-C-5015
Backshell Type	SOLID
Body Breadth	1.319 inch
Body Length	1.319 inch
Body/Shell Style	PLUG
Connector Type	CIRCULAR CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Finish - Termination	Silver (Ag)
Contact Gender	FEMALE
Contact Material	NOT SPECIFIED
Contact Style	RND PIN-SKT
Coupling Type	THREADED
DIN Conformance	NO
Dielectric Withstanding Voltage	500VAC V
Empty Shell	NO
Filter Feature	NO
IEC Conformance	NO
Insulator Color	BLACK
JESD-609 Code	e4
MIL Conformance	YES
Manufacturer Series	H/MS
Mixed Contacts	NO
Mounting Style	STRAIGHT
Mounting Type	CABLE
Number of Ports	1
Option	WATERPROOF
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	23 A
Reference Standard	UL
Reliability	COMMERCIAL
Shell Finish	ZINC
Shell Material	ALUMINUM ALLOY/ZINC ALLOY
Shell Size	18
Sub Category	DIN Connectors
Termination Type	SOLDER
Total Number of Contacts	4
