H/MS3102A20-29PW(11) データシート

Name: H/MS3102A20-29PW(11)
Brand: HIROSE
SKU: 400043156-0000-0000-0000

H/MS3102A20-29PW(11) - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

H/MS3102A20-29PW(11) の詳細情報

型番	H/MS3102A20-29PW(11)
メーカー	HIROSE
データシート
Additional Feature	STANDARD: MIL-C-5015
Backshell Type	SOLID
Body Breadth	1.5 inch
Body Depth	0.287 inch
Body Length	1.5 inch
Body/Shell Style	RECEPTACLE
Connector Type	MIL SERIES CONNECTOR
Contact Finish - Mating	AG
Contact Finish - Termination	SILVER
Contact Gender	MALE
Contact Material	COPPER ALLOY
Contact Resistance	5 mohm
Contact Style	RND PIN-SKT
Coupling Type	THREADED
DIN Conformance	NO
Dielectric Withstanding Voltage	2000VAC V
Empty Shell	NO
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	5000000000 ohm
Insulator Color	BLACK
JESD-609 Code	e4
MIL Conformance	YES
Manufacturer Series	H/MS
Mixed Contacts	NO
Mounting Style	STRAIGHT
Mounting Type	CABLE
Number of Ports	1
Option	WATERPROOF
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	13 A
Reference Standard	UL
Reliability	COMMERCIAL
Shell Finish	ZINC
Shell Material	ALUMINUM ALLOY/ZINC ALLOY
Shell Size	20
Sub Category	DIN Connectors
Terminal Length	0.142 inch
Termination Type	SOLDER
Total Number of Contacts	17
