FX8C-60S-SV5(91) データシート

Name: FX8C-60S-SV5(91)
Brand: HIROSE
SKU: 160141396-0000-0000-0000

FX8C-60S-SV5(91) - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

マガジン梱包

FX8C-60S-SV5(91) の詳細情報

型番	FX8C-60S-SV5(91)
メーカー	HIROSE
データシート
Body Breadth	0.22 inch
Body Depth	0.382 inch
Body Length	0.969 inch
Body/Shell Style	PLUG
Connector Type	BOARD STACKING CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Gender	FEMALE
Contact Material	NOT SPECIFIED
Contact Pattern	RECTANGULAR
Contact Resistance	80 mohm
Contact Style	BELLOWED TYPE
Durability	50 Cycles
Insulation Resistance	100000000 ohm
Insulator Color	BROWN
Insulator Material	POLYPHENYLENE SULFIDE
Manufacturer Series	FX8C-60S-SV5(91)
Mating Contact Pitch	0.024 inch
Mounting Option 1	LOCKING
Mounting Style	STRAIGHT
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	2
Number of Rows Loaded	2
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
PCB Contact Pattern	RECTANGULAR
PCB Contact Row Spacing	4.445 mm
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	0.4 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Terminal Pitch	.6096 mm
Termination Type	SURFACE MOUNT
Total Number of Contacts	60
