FH55-40S-0.5SH データシート

Name: FH55-40S-0.5SH
Brand: HIROSE
SKU: 400022110-0000-0000-0000

FH55-40S-0.5SH - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

FH55-40S-0.5SH の詳細情報

型番	FH55-40S-0.5SH
メーカー	HIROSE
データシート
Board Mounting Option	SOLDER HOLDING POSTS
Body/Shell Style	PLUG
Connector Type	FFC/FPC CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Finish - Termination	NOT APPLICABLE
Contact Gender	MALE
Contact Material	NOT SPECIFIED
Contact Pattern	RECTANGULAR
Contact Resistance	100 mohm
Dielectric Withstanding Voltage	200VAC V
Durability	20 Cycles
Insertion Force-Max	ZIF N
Insulation Resistance	500000000 ohm
Insulator Material	LIQUID CRYSTAL POLYMER
Mating Contact Pitch	0.019 inch
Mounting Option 1	LOCKING
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	1
Number of Rows Loaded	1
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
PCB Contact Pattern	RECTANGULAR
Rated Current (Signal)	0.5 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Terminal Pitch	.508 mm
Termination Type	SURFACE MOUNT
Total Number of Contacts	40
