DX10J-26S-CR3(50) データシート

Name: DX10J-26S-CR3(50)
Brand: HIROSE
SKU: 140187307-0000-0000-0000

DX10J-26S-CR3(50) - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

DX10J-26S-CR3(50) の詳細情報

型番	DX10J-26S-CR3(50)
メーカー	HIROSE
データシート
Body Breadth	0.413 inch
Body Depth	0.504 inch
Body Length	2.065 inch
Body/Shell Style	PLUG-RECEPTACLE
Contact Arrangement	S26C3
Contact Finish - Mating	AU
Contact Gender	MALE/FEMALE
Contact Material	COPPER ALLOY
Dielectric Withstanding Voltage	424VAC V
Durability	1000 Cycles
Insulation Resistance	250000000 ohm
Insulator Color	BLACK
Insulator Material	POLYBUTYLENE TEREPHTHALATE
Mixed Contacts	YES
Mounting Option 1	LOCKING
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number Of Connectors	ONE
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
Plating Thickness	12u inch
Rated Current (Signal)	0.5 A
Reference Standard	UL
Reliability	COMMERCIAL
Shell Finish	NICKEL
Sub Category	D Type Connectors
Terminal Length	0.154 inch
Termination Type	SOLDER
Total Number of Contacts	29
