DM3AT-SF-PEJM5 データシート

Name: DM3AT-SF-PEJM5
Brand: HIROSE
SKU: 140193261-0000-0000-0000

DM3AT-SF-PEJM5 - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

DM3AT-SF-PEJM5 の詳細情報

型番	DM3AT-SF-PEJM5
メーカー	HIROSE
データシート
Body Breadth	0.066 inch
Body Depth	0.628 inch
Body Length	0.545 inch
Body/Shell Style	RECEPTACLE
Connector Type	PCB CONNECTOR
Contact Finish - Mating	AU
Contact Finish - Termination	GOLD
Contact Gender	MALE
Contact Material	COPPER ALLOY
Contact Pattern	RECTANGULAR
Contact Resistance	100 mohm
Contact Style	COMPRESSION
DIN Conformance	NO
Dielectric Withstanding Voltage	500VAC V
Durability	10000 Cycles
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	1000000000 ohm
Insulator Color	BLACK
Insulator Material	LIQUID CRYSTAL POLYMER
JESD-609 Code	e4
MIL Conformance	NO
Manufacturer Series	DM3
Mating Contact Pitch	0.043 inch
Mixed Contacts	NO
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	1
Number of Ports	1
Number of Rows Loaded	1
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-25 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	RECTANGULAR
Rated Current (Signal)	0.5 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Terminal Pitch	1.0922 mm
Termination Type	SURFACE MOUNT
Total Number of Contacts	8
