DF1BA-7EP-2.5RC データシート

Name: DF1BA-7EP-2.5RC
Brand: HIROSE
SKU: 140079172-0000-0000-0000

DF1BA-7EP-2.5RC - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

DF1BA-7EP-2.5RC の詳細情報

型番	DF1BA-7EP-2.5RC
メーカー	HIROSE
データシート
Additional Feature	COMPATIBLE CONTACTS: DF1B-2022PCF; DF1B-2022PCFB
Body Breadth	0.319 inch
Body Depth	0.728 inch
Body Length	0.772 inch
Body/Shell Style	PLUG
Connector Type	BOARD CONNECTOR
Contact Design	PREASSEM CONN
Contact Finish - Mating	AU
Contact Finish - Termination	NOT APPLICABLE
Contact Gender	MALE
Contact Material	NOT SPECIFIED
Contact Pattern	RECTANGULAR
Contact Resistance	30 mohm
Contact Style	SQ PIN-SKT
DIN Conformance	NO
Dielectric Withstanding Voltage	650VAC V
Durability	50 Cycles
Filter Feature	NO
IEC Conformance	NO
Insertion Force-Max	4.3924 N
Insulation Resistance	1000000000 ohm
Insulator Color	WHITE
Insulator Material	POLYAMIDE
MIL Conformance	NO
Manufacturer Series	DF1B
Mating Contact Pitch	0.098 inch
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Option 1	LATCH
Mounting Option 2	LOCKING
Mounting Type	CABLE
Number of Rows Loaded	1
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-35 Cel
Option	GENERAL PURPOSE
Polarization Key	HOUSING SIDE
Rated Current (Signal)	3 A
Reference Standard	UL, CSA
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Termination Type	CRIMP AND IDC
Total Number of Contacts	7
UL Flammability Code	94V-0
Wire Size-Max	20 AWG
Wire Size-Min	30 AWG
Withdrawl Force-Min	.417 N
