DF1-4P-2.5DS データシート

Name: DF1-4P-2.5DS
Brand: HIROSE
SKU: 400068563-0000-0000-0000

DF1-4P-2.5DS - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

DF1-4P-2.5DS の詳細情報

型番	DF1-4P-2.5DS
メーカー	HIROSE
データシート
Additional Feature	LOW PROFILE
Body Breadth	0.236 inch
Body Depth	0.295 inch
Body Length	0.492 inch
Body/Shell Style	RECEPTACLE
Connector Type	BOARD CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Finish - Termination	TIN
Contact Gender	MALE
Contact Material	BRASS
Contact Pattern	RECTANGULAR
Contact Resistance	30 mohm
Contact Resistance (mohm)	30
Contact Style	IDC
DIN Conformance	NO
Dielectric Withstanding Voltage	650VAC V
Dielectric Withstanding Voltage (V)	650VAC
Durability	30 Cycles
Durability (Cycles)	30
Filter Feature	NO
IEC Conformance	NO
Insertion Force-Max	4.3924 N
Insertion Force-Max (N)	4.3924
Insulation Resistance	1000000000 ohm
Insulation Resistance (ohm)	1000000000
Insulator Color	BROWN
Insulator Material	POLYAMIDE
J-STD-609 Code	e3
JESD-609 Code	e3
MIL Conformance	NO
Manufacturer Series	DF1
Mating Contact Pitch	0.098 inch
Mating Contact Pitch (inch)	0.098
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	1
Number of Connectors	ONE
Number of Contacts	4
Number of PCB Rows	1
Number of Rows Loaded	1
Option	GENERAL PURPOSE
PCB Contact Pattern	RECTANGULAR
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Termination Type	SOLDER
UL Flammability Code	94V-0
