DF13-2630SCF データシート

Name: DF13-2630SCF
Brand: HIROSE
SKU: 140078699-0000-0000-0000

DF13-2630SCF - HIROSE の商品詳細ページです。

２営業日以内に回答いたします

DF13-2630SCF の詳細情報

型番	DF13-2630SCF
メーカー	HIROSE
データシート
Additional Feature	CONTACT FINISH: GOLD
Approvals	UL V
Assembly Item Name	CONTACT
Cable Entry-Max	0.039 inch
Cable Entry-Min	0.025 inch
Cable Types	UL1571, UL1061
Connector Support Type	CONNECTOR ACCESSORY
Contact Gender	FEMALE
Contact Resistance	30 mohm
Contact Style	BELLOWED CONTACT
DIN Conformance	NO
Design Use	SIGNAL
Finish Thickness	8
IEC Conformance	NO
Insulator Material	POLYAMIDE
MIL Conformance	NO
Manufacturer Series	DF13
Material	PHOSPHOR BRONZE
Mfr Name	HIROSE ELECTRIC CO LTD
Mfr P/N	DF13-2630SCF
Mounting Style	STRAIGHT
New Category	Assembly Items
New Part Type	CONNECTOR_SUPPORT
Old Category	Terminals and Terminal Blocks
Old Part Type	TERMINALS_AND_TERMINAL_BLOCKS
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-35 Cel
Part Objectid	1209299860
Rated Current	1 A
Rated Voltage (AC)	150 V
Terminal Length	0.079 inch
Terminal Type	CRIMP
Used With	DF13 SERIES CONNECTOR
Wire Size-Max	26 AWG
Wire Size-Min	30 AWG
