HA1-2405-5 の詳細情報

  • 仕様・詳細
  • メーカー情報
型番HA1-2405-5
メーカーHARRIS
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Average Bias Current-Max (IIB) 0.25 uA
Bias Current-Max (IIB) @25C 0.25 uA
Common-mode Reject Ratio-Min 74 dB
Common-mode Reject Ratio-Nom 100 dB
Frequency Compensation YES (AVCL>=10)
Input Offset Voltage-Max 9000 uV
JESD-30 Code R-GDIP-T16
JESD-609 Code e0
Low-Offset NO
Neg Supply Voltage Limit-Max -22.5 V
Neg Supply Voltage-Nom (Vsup) -15 V
Number of Functions 1
Number of Terminals 16
Operating Temperature-Max 70 Cel
Operating Temperature-Min 0 Cel
Package Body Material CERAMIC
Package Code DIP
Package Equivalence Code DIP16,.3
Package Shape RECTANGULAR
Package Style IN-LINE Meter
Power Supplies +-15 V
Qualification Status Not Qualified
Seated Height-Max 5.08 mm
Slew Rate-Min 6 V/us
Slew Rate-Nom 8 V/us
Sub Category Operational Amplifier
Supply Current-Max 6 mA
Supply Voltage Limit-Max 22.5 V
Supply Voltage-Nom (Vsup) 15 V
Surface Mount NO
Technology BIPOLAR
Temperature Grade COMMERCIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Unity Gain BW-Nom 8000 kHz
Voltage Gain-Min 25000
Width 7.62 mm
