S5821-01 データシート

Name: S5821-01
Brand: HAMAMATSU
SKU: 290251584-0000-0000-0000

S5821-01 - HAMAMATSU の商品詳細ページです。

２営業日以内に回答いたします

S5821-01 の詳細情報

型番	S5821-01
メーカー	HAMAMATSU
データシート
Additional Feature	HIGH RELIABILITY
Configuration	SINGLE
Dark Current-Max	2 nA
Infrared Range	YES
Light Current-Nom	0.012 mA
Mounting Feature	THROUGH HOLE MOUNT
Number of Functions	1
Operating Temperature-Max	100 Cel
Operating Temperature-Min	-40 Cel
Optoelectronic Device Type	PIN PHOTODIODE
Peak Wavelength	960 nm
Reverse Breakdown Voltage-Min	20 V
Reverse Voltage-Max	20 V
Semiconductor Material	Silicon
Shape	ROUND
Size	4.65 mm
Sub Category	Photo Diodes
