MBM29DL640E90TN データシート

Name: MBM29DL640E90TN
Brand: FUJITSU
SKU: 230045274-0000-0000-0000

MBM29DL640E90TN - FUJITSU の商品詳細ページです。

２営業日以内に回答いたします

MBM29DL640E90TN の詳細情報

型番	MBM29DL640E90TN
メーカー	FUJITSU
データシート
Access Time-Max	90 ns
Additional Feature	CONFIGURABLE AS 8M X 8
Alternate Memory Width	8
Boot Block	BOTTOM/TOP
Command User Interface	YES
Common Flash Interface	YES
Data Polling	YES
JESD-30 Code	R-PDSO-G48
JESD-609 Code	e0
Length	18.4 mm
Memory Density	67108864 bit
Memory IC Type	FLASH
Memory Width	16
Number of Functions	1
Number of Sectors/Size	16,126
Number of Terminals	48
Number of Words	4194304 words
Number of Words Code	4M
Operating Mode	ASYNCHRONOUS
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Organization	4MX16
Package Body Material	PLASTIC/EPOXY
Package Code	TSOP1
Package Equivalence Code	TSSOP48,.8,20
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE Meter
Parallel/Serial	PARALLEL
Power Supplies	3/3.3 V
Programming Voltage	3 V
Qualification Status	Not Qualified
Ready/Busy	YES
Seated Height-Max	1.2 mm
Sector Size	8K,64K Words
Standby Current-Max	5.0E-6 Amp
Sub Category	Flash Memories
Supply Current-Max	0.058 mA
Supply Voltage-Max (Vsup)	3.6 V
Supply Voltage-Min (Vsup)	2.7 V
Supply Voltage-Nom (Vsup)	3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	DUAL
Toggle Bit	YES
Type	NOR TYPE
Width	12 mm
