MB90092PF データシート

Name: MB90092PF
Brand: FUJITSU
SKU: 230423060-0000-0000-0000

MB90092PF - FUJITSU の商品詳細ページです。

２営業日以内に回答いたします

MB90092PF の詳細情報

型番	MB90092PF
メーカー	FUJITSU
データシート
Address Bus Width	0
Clock Frequency-Max	16 MHz
Display Configuration	24 X 12 CHARACTERS
External Data Bus Width	8
JESD-30 Code	R-PQFP-G80
JESD-609 Code	e0
Length	20 mm
Number of Terminals	80
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	QFP
Package Equivalence Code	QFP80,.7X.9,32
Package Shape	RECTANGULAR
Package Style	FLATPACK Meter
Power Supplies	5 V
Qualification Status	Not Qualified
Seated Height-Max	3.05 mm
Sub Category	Display Controllers
Supply Voltage-Max	5.5 V
Supply Voltage-Min	4.5 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	TIN LEAD
Terminal Form	GULL WING
Terminal Pitch	0.8 mm
Terminal Position	QUAD
Width	14 mm
uPs/uCs/Peripheral ICs Type	DISPLAY CONTROLLER, CRT CHARACTER OR GRAPHICS DISPLAY
