MB85RS256BPNF-G-JNE1

Name: MB85RS256BPNF-G-JNE1
Brand: FUJITSU
SKU: 400007048-0000-0000-0000

MB85RS256BPNF-G-JNE1 - FUJITSU の商品詳細ページです。

２営業日以内に回答いたします

MB85RS256BPNF-G-JNE1 の詳細情報

型番	MB85RS256BPNF-G-JNE1
メーカー	FUJITSU
JESD-30 Code	R-PDSO-G8
Length	5.05 mm
Memory Density	262144 bit
Memory IC Type	MEMORY CIRCUIT
Memory Width	8
Number of Functions	1
Number of Terminals	8
Number of Words	32768 words
Number of Words Code	32K
Operating Mode	SYNCHRONOUS
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Organization	32KX8
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP8,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	3.3 V
Qualification Status	Not Qualified
Seated Height-Max	1.75 mm
Standby Current-Max	5.0E-5 Amp
Sub Category	SRAMs
Supply Current-Max	0.006 mA
Supply Voltage-Max (Vsup)	3.6 V
Supply Voltage-Min (Vsup)	2.7 V
Supply Voltage-Nom (Vsup)	3.3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	3.9 mm
