MB81461-15-PSZ データシート

Name: MB81461-15-PSZ
Brand: FUJITSU
SKU: 230333866-0000-0000-0000

MB81461-15-PSZ - FUJITSU の商品詳細ページです。

２営業日以内に回答いたします

MB81461-15-PSZ の詳細情報

型番	MB81461-15-PSZ
メーカー	FUJITSU
データシート
Access Mode	PAGE
Access Time-Max	150 ns
Additional Feature	RAS ONLY/CAS BEFORE RAS/HIDDEN REFRESH; 256 X 4 SAM PORT
JESD-30 Code	R-PZIP-T24
JESD-609 Code	e0
Length	30.71 mm
Memory Density	262144 bit
Memory IC Type	VIDEO DRAM
Memory Width	4
Number of Functions	1
Number of Ports	2
Number of Terminals	24
Number of Words	65536 words
Number of Words Code	64K
Operating Mode	ASYNCHRONOUS
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Organization	64KX4
Output Characteristics	3-STATE
Package Body Material	PLASTIC/EPOXY
Package Code	ZIP
Package Equivalence Code	ZIP24,.1
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Power Supplies	5 V
Qualification Status	Not Qualified
Refresh Cycles	256
Seated Height-Max	10.16 mm
Standby Current-Max	0.02 Amp
Sub Category	Other Memory ICs
Supply Current-Max	0.085 mA
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	4.5 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	NO
Technology	MOS
Temperature Grade	COMMERCIAL
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	THROUGH-HOLE
Terminal Pitch	1.27 mm
Terminal Position	ZIG-ZAG
Width	2.85 mm
