MB3773P データシート

Name: MB3773P
Brand: FUJITSU
SKU: 230007152-0000-0000-0000

MB3773P - FUJITSU の商品詳細ページです。

２営業日以内に回答いたします

MB3773P の詳細情報

型番	MB3773P
メーカー	FUJITSU
データシート
Additional Feature	DETECTION THRESHOLD VOLTAGE IS 4.2
Adjustable Threshold	NO
Analog IC - Other Type	POWER SUPPLY MANAGEMENT CIRCUIT
JESD-30 Code	R-PDIP-T8
JESD-609 Code	e6
Length	6.35 mm
Number of Channels	1
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP8,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	5 V
Qualification Status	Not Qualified
Seated Height-Max	2.25 mm
Sub Category	Power Management Circuits
Supply Current-Max (Isup)	0.9 mA
Supply Voltage-Max (Vsup)	16 V
Supply Voltage-Min (Vsup)	3.5 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	NO
Technology	BIPOLAR
Temperature Grade	INDUSTRIAL
Terminal Finish	TIN BISMUTH
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Threshold Voltage-Nom	+4.2V V
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	3.26 mm
