FTR-P3CN010W1 データシート

Name: FTR-P3CN010W1
Brand: FUJITSU
SKU: 160125446-0000-0000-0000

FTR-P3CN010W1 - FUJITSU の商品詳細ページです。

２営業日以内に回答いたします

FTR-P3CN010W1 の詳細情報

型番	FTR-P3CN010W1
メーカー	FUJITSU
データシート
Body Breadth	7.2 inch
Body Height	13.5 mm
Body Length or Diameter	17.4 mm
Coil Current(DC)-Max	0.06 A
Coil Operate Voltage(DC)	7.9 V
Coil Power	600 mW
Coil Release Voltage(DC)	0.9 V
Coil Resistance	167 ohm
Coil Voltage(DC)-Max	10 V
Coil Voltage-Nom	10 V
Coil/Input Supply Type	DC
Contact AC Max Rating R Load	35A@16VDC
Contact Current(DC)-Max	25 A
Contact DC Max Rating R Load	25A@14VDC
Contact Voltage(DC)-Max	14 V
Contact/Output Supply Type	DC
Dielectric Strength Between Coil and Contacts	500 Vrms
Dielectric Strength Between Open Contacts	500 Vrms
Electrical Life	100000 Cycle(s)
Input Switching Control Type	Random
Insulation Resistance	100000000 ohm
Manufacturer Series	FTR-P3
Mounting Feature	THROUGH HOLE-STRAIGHT MOUNT
Number of Terminals	5
Operate Time	10 ms
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
PCB Hole Count	5
Packing Method	TUBE
Physical Dimension	17.4mm X 7.2mm X 13.5mm
Relay Action	MOMENTARY
Relay Form	1 FORM C
Relay Function	SPDT
Relay Type	POWER/SIGNAL RELAY
Release Time	5 ms
Terminal Length	0.002 inch
Termination Type	SOLDER
Weight	5 g
