FCN-361J008-AU の詳細情報

型番	FCN-361J008-AU
メーカー	FUJITSU
データシート
Board Mounting Option	MOUNTING FLANGE
Body Breadth	0.324 inch
Body Depth	0.228 inch
Body Length	1.135 inch
Body/Shell Style	JACK
Connector Type	TELECOM AND DATACOM CONNECTOR
Contact Design	PREASSEM CONN
Contact Finish - Mating	GOLD SILVER
Contact Finish - Termination	GOLD SILVER
Contact Gender	FEMALE
Contact Material	COPPER ALLOY
Contact Pattern	RECTANGULAR
Contact Resistance	15 mohm
Contact Style	SQ PIN-SKT
DIN Conformance	NO
Dielectric Withstanding Voltage	500VAC V
Empty Shell	NO
Filter Feature	NO
IEC Conformance	NO
Insertion Force-Max	3.058 N
Insulation Diameter-Min	0.024 inch
Insulation Resistance	1000000000 ohm
Insulator Material	POLYESTER
MIL Conformance	NO
Mating Contact Pitch	0.1 inch
Mating Contact Row Spacing	0.1 inch
Mixed Contacts	NO
Mounting Option 1	HOLE .099-.111
Mounting Option 2	MOUNTING FLANGE
Mounting Type	CABLE AND PANEL
Number of Rows Loaded	2
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
Option	GENERAL PURPOSE
Rated Current (Signal)	3 A
Reliability	COMMERCIAL
Sub Category	D Type Connectors
Terminal Length	0.197 inch
Termination Type	SOLDER
Total Number of Contacts	8
UL Flammability Code	94V-2
Wire Size-Max	23 AWG
Wire Size-Min	23 AWG
Withdrawl Force-Min	.3614 N
