TM2-21-L2 データシート

Name: TM2-21-L2
Brand: FUJISOKU
SKU: 400067896-0000-0000-0000

TM2-21-L2 - FUJISOKU の商品詳細ページです。

２営業日以内に回答いたします

TM2-21-L2 の詳細情報

型番	TM2-21-L2
メーカー	FUJISOKU
データシート
Actuator Angle (deg)	0
Actuator Length (inch)	0.098
Actuator Travel (mm)	.254
Actuator Type	PUSHBUTTON
Additional Feature	RED LED
Body Breadth (mm)	5.8928
Body Height (mm)	6.5024
Body Length or Diameter (mm)	7.0104
Bushing Length (inch)	0
Center Contact Plating	SILVER
Contact Current(DC)-Max (A)	0.05
Contact DC Max Rating R Load	0.05A@48VDC
Contact Function	OFF-(ON)
Contact Resistance (mohm)	100
Contact Timing	BREAK-BEFORE-MAKE
Contact Voltage(DC)-Max (V)	48
Dielectric Withstand Volts (V)	250VAC
Electrical Life (Cycle(s))	300000
End Contact Plating	SILVER
Illumination	LED
Insulation Resistance (ohm)	100000000
J-STD-609 Code	e4
Manufacturer Series	TM
Mounting Feature	THROUGH HOLE-STRAIGHT
Operating Temperature-Max (Cel)	70
Operating Temperature-Min (Cel)	-25
PCB Hole Count	7
Solderability	HAND
Switch Action	MOMENTARY
Switch Function	SPST
Switch Type	PUSHBUTTON SWITCH
Terminal Finish	SILVER
Terminal Length (inch)	0.276
Termination Type	SOLDER
Washability	SOLVENT
