SDG5101SX Fujisoku

SDG5101SX - FUJISOKU の商品詳細ページです。

1
SDG5101SX
  • SDG5101SX
  • SDG5101SX
  • SDG5101SX
  • SDG5101SX
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • 個
２営業日以内に回答いたします
この商品のお問い合わせ

SDG5101SX の詳細情報

  • 仕様・詳細
  • メーカー情報
型番SDG5101SX
メーカーFUJISOKU
Actuator Color BLACK
Actuator Finish MATTE
Actuator Length 0.079 inch
Actuator Type THUMBWHEEL
Additional Feature DOUBLE DUST RESIS.,ODD PARITY
Body Breadth 16.002 inch
Body Color BLACK
Body Height 28.4988 mm
Body Length or Diameter 30.5054 mm
Bushing Length 0 inch
Contact AC Max Rating R Load 0.05A@28VAC
Contact Current(AC)-Max 0.05 A
Contact Current(DC)-Max 0.05 A
Contact DC Max Rating R Load 0.05A@28VDC
Contact Function ON-ON
Contact Resistance 0.2 mohm
Contact Timing BREAK-BEFORE-MAKE
Contact Voltage(AC)-Max 28 V
Contact Voltage(DC)-Max 28 V
Dielectric Withstand Volts 500VDC V
Electrical Life 1000000 Cycle(s)
Insulation Resistance 1000000000 ohm
Manufacturer Series SDG5000
Mounting Feature PANEL MOUNT
Number of Positions 10
Switch Action CIRCULAR
Switch Function BINARY CODED DECIMAL
Switch Type THUMB/PUSHWHEEL SWITCH
Termination Type SOLDER LUG
会社名称NIDEC COPAL ELECTRONICS CORP.
設立1947
資本金JPY 389,000,000
所在地24-12, Sumiyoshi-cho, Kizuki, Nakahara-ku, Kawasaki-shi, Kanagawa-ken, 211-0021 Japan
URLhttp://www.nidec-copal-electronics.com/
