2SD1073

Name: 2SD1073
Brand: FUJI ELE
SKU: 30112454-0000-0000-0000

2SD1073 - FUJI ELE の商品詳細ページです。

２営業日以内に回答いたします

NPN型バイポーラトランジスタ | 低周波用

2SD1073 の詳細情報

型番	2SD1073
メーカー	FUJI ELE
種別	バイポーラトランジスタ
Additional Feature	HIGH RELIABILITY
Case Connection	COLLECTOR
Collector Current-Max (IC)	4 A
Collector-emitter Voltage-Max	250 V
Configuration	DARLINGTON
DC Current Gain-Min (hFE)	1000
JEDEC-95 Code	TO-220AB
JESD-30 Code	R-PSFM-T3
Number of Elements	1
Number of Terminals	3
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	FLANGE MOUNT Meter
Polarity/Channel Type	NPN
Power Dissipation Ambient-Max	60 W
Power Dissipation-Max (Abs)	60 W
Qualification Status	Not Qualified
Sub Category	Other Transistors
Surface Mount	NO
Terminal Form	THROUGH-HOLE
Terminal Position	SINGLE
Transistor Application	SWITCHING
Transistor Element Material	SILICON
Turn-off Time-Max (toff)	25000 ns
Turn-on Time-Max (ton)	3000 ns
