FT230XS-U の詳細情報

  • 仕様・詳細
  • メーカー情報
型番FT230XS-U
メーカーFTDI
Bus Compatibility UART, USB
Clock Frequency-Max 12.02 MHz
Data Transfer Rate-Max 60 MBps
JESD-30 Code R-PDSO-G16
JESD-609 Code e3
Length 4.9022 mm
Moisture Sensitivity Level 3
Number of Terminals 16
Operating Temperature-Max 85 Cel
Operating Temperature-Min -40 Cel
Package Body Material PLASTIC/EPOXY
Package Code SSOP
Package Equivalence Code SSOP16,.25
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel) 260
Power Supplies 1.8/3.3,3.3/5 V
Qualification Status Not Qualified
Seated Height-Max 1.7526 mm
Sub Category Serial IO/Communication Controllers
Supply Current-Max 8.3 mA
Supply Voltage-Max 5.5 V
Supply Voltage-Min 2.97 V
Supply Voltage-Nom 5 V
Surface Mount YES
Technology CMOS
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Pitch 0.635 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Width 3.9116 mm
uPs/uCs/Peripheral ICs Type BUS CONTROLLER, UNIVERSAL SERIAL BUS
会社名称Future Technology Devices International Limited
所在地Unit 1, 2 Seaward Place Centurion Business Park Glasgow G41 1HH United Kingdom
URLhttp://www.ftdichip.com/
