KMPC8270CVRMIBA データシート

Name: KMPC8270CVRMIBA
Brand: FREESCALE
SKU: 210018062-0000-0000-0000

KMPC8270CVRMIBA - FREESCALE の商品詳細ページです。

２営業日以内に回答いたします

KMPC8270CVRMIBA の詳細情報

型番	KMPC8270CVRMIBA
メーカー	FREESCALE
データシート
Address Bus Width	32
Bit Size	32
Boundary Scan	YES
Clock Frequency-Max	266 MHz
External Data Bus Width	64
Format	FLOATING POINT
Integrated Cache	YES
JESD-30 Code	S-PBGA-B516
JESD-609 Code	e2
Length	27 mm
Low Power Mode	NO
Moisture Sensitivity Level	3
Number of Terminals	516
Package Body Material	PLASTIC/EPOXY
Package Code	BGA
Package Shape	SQUARE
Package Style	GRID ARRAY Meter
Peak Reflow Temperature (Cel)	245
Qualification Status	Not Qualified
Seated Height-Max	2.55 mm
Speed	66.67 rpm
Supply Voltage-Max	1.6 V
Supply Voltage-Min	1.45 V
Supply Voltage-Nom	1.5 V
Surface Mount	YES
Technology	CMOS
Terminal Finish	TIN SILVER
Terminal Form	BALL
Terminal Pitch	1 mm
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	30
Width	27 mm
uPs/uCs/Peripheral ICs Type	MICROPROCESSOR, RISC

会社名称	Freescale Semiconductor, Inc.
所在地	6501 William Cannon Drive West Austin, Texas 78735,USA
URL	http://www.freescale.com/
