HM2R04P1 の詳細情報

型番	HM2R04P1
メーカー	FCI
データシート
Additional Feature	STANDARDS: IEC 917; IEC 61076-4-101, COMPATIBLE CONTACTS: RC12PIE70ERP; RC12PIE75ERP, HIGH DENSITY, POLARIZATION AVAILABLE
Board Mounting Option	LOCATING POSTS
Body Breadth	0.449 inch
Body Depth	0.799 inch
Body Length	1.969 inch
Body/Shell Style	PLUG
Connector Type	BOARD CONNECTOR
Contact Arrangement	S0P6
Contact Finish - Mating	GOLD OVER NICKEL
Contact Finish - Termination	GOLD OVER NICKEL
Contact Gender	FEMALE
Contact Material	NOT SPECIFIED
Contact Pattern	RECTANGULAR
Contact Style	RND PIN-SKT
DIN Conformance	NO
Filter Feature	NO
IEC Conformance	YES
Insulator Material	POLYETHYLENE
JESD-609 Code	e4
MIL Conformance	NO
Mating Contact Pitch	0.295 inch
Mixed Contacts	NO
Mounting Option 1	GUIDE PIN
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	2
Number of Rows Loaded	1
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-55 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	RECTANGULAR
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Terminal Length	0.149 inch
Terminal Pitch	7.5 mm
Termination Type	CRIMP/PRESS FIT/SOLDER
Total Number of Contacts	6
UL Flammability Code	94V-0
