65043-028

Name: 65043-028
Brand: FCI
SKU: 70032456-0000-0000-0000

65043-028 - FCI の商品詳細ページです。

２営業日以内に回答いたします

65043-028 の詳細情報

型番	65043-028
メーカー	FCI
Additional Feature	BAG PACKAGING
Body Breadth	0.2 inch
Body Depth	0.545 inch
Body Length	0.886 inch
Body/Shell Style	PLUG
Connector Type	BOARD CONNECTOR
Contact Design	PREASSEM CONN
Contact Finish - Mating	NOT SPECIFIED
Contact Gender	FEMALE
Contact Material	NOT SPECIFIED
Contact Pattern	RECTANGULAR
Contact Resistance	2 mohm
Contact Style	SQ PIN-SKT
DIN Conformance	NO
Dielectric Withstanding Voltage	1400VAC V
Durability	1000 Cycles
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	5000000000 ohm
Insulator Color	BLACK
Insulator Material	POLYETHYLENE
MIL Conformance	NO
Manufacturer Series	65043
Mating Contact Pitch	0.1 inch
Mating Contact Row Spacing	0.1 inch
Mixed Contacts	NO
Mounting Option 1	LATCH
Mounting Option 2	LATCH
Mounting Style	STRAIGHT
Mounting Type	CABLE
Number Of Connectors	ONE
Number of Rows Loaded	2
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-40 Cel
Option	GENERAL PURPOSE
Polarization Key	POLARIZED HOUSING
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Termination Type	CRIMP
Total Number of Contacts	18
UL Flammability Code	94V-0
Wire Size-Max	22 AWG
Wire Size-Min	36 AWG
