UA9638RC
1
-
- 個
２営業日以内に回答いたします
UA9638RC の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | UA9638RC |
|---|---|
| メーカー | FAIRCHILD |
| Differential Output | YES |
| Driver Number of Bits | 1 |
| High Level Input Current-Max | 2.5E-5 Amp |
| Input Characteristics | STANDARD |
| Interface IC Type | LINE DRIVER |
| Interface Standard | EIA-422 |
| JESD-30 Code | R-CDIP-T8 |
| JESD-609 Code | e0 |
| Moisture Sensitivity Level | 2A |
| Number of Functions | 2 |
| Number of Terminals | 8 |
| Operating Temperature-Max | 70 Cel |
| Operating Temperature-Min | 0 Cel |
| Out Swing-Min | 2 V |
| Output Characteristics | TOTEM-POLE |
| Output Polarity | COMPLEMENTARY |
| Package Body Material | CERAMIC |
| Package Code | DIP |
| Package Equivalence Code | DIP8,.3 |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE Meter |
| Power Supplies | 5 V |
| Qualification Status | Not Qualified |
| Receive Delay-Max | 0 ns |
| Seated Height-Max | 5.08 mm |
| Sub Category | Line Driver or Receivers |
| Supply Voltage-Max | 5.25 V |
| Supply Voltage-Min | 4.75 V |
| Supply Voltage-Nom | 5 V |
| Surface Mount | NO |
| Technology | BIPOLAR |
| Temperature Grade | COMMERCIAL |
| Terminal Finish | TIN LEAD |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 mm |
| Terminal Position | DUAL |
| Transmit Delay-Max | 20 ns |
| Width | 7.62 mm |
| 会社名称 | Fairchild Semiconductor Corporation |
|---|---|
| 設立 | 1957 |
| 所在地 | 3030 Orchard Parkway San Jose, CA 95134 United States |
| URL | http://www.fairchildsemi.com/ |
