UA7915UC
1
-
- 個
２営業日以内に回答いたします
UA7915UC の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | UA7915UC |
|---|---|
| メーカー | FAIRCHILD |
| Adjustability | FIXED |
| Input Voltage-Max | 35 V |
| Input Voltage-Min | 17.3 V |
| JESD-30 Code | R-XSFM-T3 |
| JESD-609 Code | e0 |
| Line Regulation-Max | 0.3 % |
| Number of Functions | 1 |
| Number of Outputs | 1 |
| Number of Terminals | 3 |
| Operating Temperature, TJ-Max | 125 Cel |
| Operating Temperature, TJ-Min | 0 Cel |
| Output Current1-Max | 1 A |
| Output Voltage1-Nom | -15 V |
| Package Body Material | PLASTIC/EPOXY |
| Package Equivalence Code | SIP3,.1TB |
| Package Shape | RECTANGULAR |
| Package Style | FLANGE MOUNT Meter |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Qualification Status | Not Qualified |
| Regulator Type | FIXED NEGATIVE SINGLE OUTPUT STANDARD REGULATOR |
| Sub Category | Other Regulators |
| Surface Mount | NO |
| Technology | BIPOLAR |
| Terminal Finish | TIN LEAD |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 mm |
| Terminal Position | SINGLE |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Voltage Tolerance-Max | 5 % |
| 会社名称 | Fairchild Semiconductor Corporation |
|---|---|
| 設立 | 1957 |
| 所在地 | 3030 Orchard Parkway San Jose, CA 95134 United States |
| URL | http://www.fairchildsemi.com/ |
