SI9410DY Fairchild

SI9410DY - FAIRCHILD の商品詳細ページです。

1
No Image
  • 個
２営業日以内に回答いたします
この商品のお問い合わせ

SI9410DY の詳細情報

  • 仕様・詳細
  • メーカー情報
型番SI9410DY
メーカーFAIRCHILD
Configuration SINGLE
DS Breakdown Voltage-Min 30 V
Drain Current-Max (Abs) (ID) 2.5 A
Drain Current-Max (ID) 0.007 A
Drain-source On Resistance-Max 0.03 ohm
FET Technology METAL-OXIDE SEMICONDUCTOR
JEDEC-95 Code MS-012AA
JESD-30 Code R-PDSO-G8
JESD-609 Code e0
Moisture Sensitivity Level 1
Number of Elements 1
Number of Terminals 8
Operating Mode ENHANCEMENT MODE
Operating Temperature-Max 150 Cel
Operating Temperature-Min -55 Cel
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style SMALL OUTLINE Meter
Polarity/Channel Type N-CHANNEL
Power Dissipation Ambient-Max 2.5 W
Power Dissipation-Max (Abs) 2.5 W
Pulsed Drain Current-Max (IDM) 30 A
Qualification Status Not Qualified
Sub Category FET General Purpose Power
Surface Mount YES
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Position DUAL
Transistor Application SWITCHING
Transistor Element Material SILICON
会社名称Fairchild Semiconductor Corporation
設立1957
所在地3030 Orchard Parkway San Jose, CA 95134 United States
URLhttp://www.fairchildsemi.com/

SI9410DYのレビュー

SI9410DY のご注文について
