MMBT5551 データシート

Name: MMBT5551
Brand: FAIRCHILD
SKU: 230009113-0000-0000-0000

MMBT5551 - FAIRCHILD の商品詳細ページです。

２営業日以内に回答いたします

MMBT5551 の詳細情報

型番	MMBT5551
メーカー	FAIRCHILD
データシート
Additional Feature	HIGH RELIABILITY
Collector Current-Max (IC)	0.06 A
Collector-base Capacitance-Max	5 pF
Collector-emitter Voltage-Max	140 V
Configuration	SINGLE
DC Current Gain-Min (hFE)	20
JEDEC-95 Code	TO-236
JESD-30 Code	R-PDSO-F3
JESD-609 Code	e0
Moisture Sensitivity Level	1
Number of Elements	1
Number of Terminals	3
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	235
Polarity/Channel Type	NPN
Power Dissipation Ambient-Max	0.225 W
Power Dissipation-Max (Abs)	0.225 W
Qualification Status	Not Qualified
Reference Standard	AEC-Q101
Sub Category	Other Transistors
Surface Mount	YES
Terminal Finish	MATTE TIN
Terminal Form	FLAT
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	5
Transistor Application	AMPLIFIER
Transistor Element Material	SILICON
Transition Frequency-Nom (fT)	80 MHz
VCEsat-Max	0.2 V
