MM88C30N
1
-
- 個
２営業日以内に回答いたします
MM88C30N の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | MM88C30N |
|---|---|
| メーカー | FAIRCHILD |
| Differential Output | YES |
| Driver Number of Bits | 1 |
| High Level Input Current-Max | 1.0E-6 Amp |
| Input Characteristics | GATED |
| Interface IC Type | LINE DRIVER |
| Interface Standard | GENERAL PURPOSE |
| JESD-30 Code | R-PDIP-T14 |
| JESD-609 Code | e0 |
| Length | 19.18 mm |
| Number of Functions | 2 |
| Number of Terminals | 14 |
| Operating Temperature-Max | 85 Cel |
| Operating Temperature-Min | -40 Cel |
| Output Characteristics | TOTEM-POLE |
| Output Polarity | COMPLEMENTARY |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | DIP |
| Package Equivalence Code | DIP14,.3 |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE Meter |
| Power Supplies | 3/15 V |
| Qualification Status | Not Qualified |
| Receive Delay-Max | 0 ns |
| Seated Height-Max | 5.08 mm |
| Sub Category | Line Driver or Receivers |
| Supply Voltage-Max | 15 V |
| Supply Voltage-Min | 3 V |
| Supply Voltage-Nom | 4.5 V |
| Surface Mount | NO |
| Technology | BICMOS |
| Temperature Grade | INDUSTRIAL |
| Terminal Finish | MATTE TIN |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 mm |
| Terminal Position | DUAL |
| Transmit Delay-Max | 400 ns |
| Width | 7.62 mm |
| 会社名称 | Fairchild Semiconductor Corporation |
|---|---|
| 設立 | 1957 |
| 所在地 | 3030 Orchard Parkway San Jose, CA 95134 United States |
| URL | http://www.fairchildsemi.com/ |
