MC79L05ACHX データシート

Name: MC79L05ACHX
Brand: FAIRCHILD
SKU: 230219948-0000-0000-0000

MC79L05ACHX - FAIRCHILD の商品詳細ページです。

２営業日以内に回答いたします

MC79L05ACHX の詳細情報

型番	MC79L05ACHX
メーカー	FAIRCHILD
データシート
Adjustability	FIXED
Dropout Voltage1-Nom	1.7 V
Input Voltage Absolute-Max	30 V
Input Voltage-Max	20 V
Input Voltage-Min	7 V
JESD-30 Code	R-PSSO-F3
JESD-609 Code	e3
Length	4.5 mm
Line Regulation-Max	0.15 %
Load Regulation-Max	0.06 %
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	3
Operating Temperature, TJ-Max	125 Cel
Operating Temperature, TJ-Min	0 Cel
Output Current1-Max	0.1 A
Output Voltage1-Max	5.25 V
Output Voltage1-Min	4.75 V
Output Voltage1-Nom	5 V
Package Body Material	PLASTIC/EPOXY
Package Code	LSOP
Package Equivalence Code	TO-243
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Regulator Type	FIXED NEGATIVE SINGLE OUTPUT STANDARD REGULATOR
Seated Height-Max	1.7 mm
Sub Category	Other Regulators
Surface Mount	YES
Technology	BIPOLAR
Terminal Finish	MATTE TIN
Terminal Form	FLAT
Terminal Pitch	1.5 mm
Terminal Position	SINGLE
Time@Peak Reflow Temperature-Max (s)	30
Voltage Tolerance-Max	5 %
Width	2.5 mm
